Rollers & Frames
Heavy-duty conveyor drum and pulley solutions engineered for demanding material handling environments across quarrying, recycling, mining, aggregates and bulk processing operations.
Planning a Roller
or Conveyor Frame Upgrade?
Explore Uni Rollers, return roller lifting cradles, transoms, conveyor frames and impact bed systems engineered to support conveyor reliability, improve maintenance access and enhance long-term operational performance across demanding material handling environments.
Engineered for Reliability
Make EnquiryQPI’s conveyor rollers, transoms, frames and impact support systems are engineered to support conveyor reliability, improve maintenance efficiency and deliver long-term operational performance across quarrying, aggregates, recycling and heavy-duty material handling environments.
Roller configurations, frame compatibility and stock availability may vary depending on operational requirements and application duty.
Conveyor Rollers,
Frames & Support Systems
Heavy-duty conveyor rollers, transoms, frames, lifting cradles and impact support systems designed to improve conveyor reliability, maintenance access and long-term material handling performance.
QPI supplies conveyor rollers, Uni Rollers, return roller lifting cradles, transoms, frames and impact bed systems tailored around belt support, tracking performance, stockholding efficiency, safe maintenance access and demanding quarrying, aggregates and recycling applications.
Explore roller shell options, shaft and bearing configurations, frame compatibility, lifting cradle systems and conveyor support components engineered for high-demand industrial environments.
Uni Rollers
Versatile roller design
for multiple terminal ends
Lifting Cradles
Safer return roller
replacement support
Transoms
Conveyor frame support
and structural alignment
Frames
In-line and staggered
conveyor frame options
Impact Beds
Loading zone support
and belt protection
3.6–12mm
Roller shell thickness
options available
20–50mm
Shaft and bearing
diameter options
5-Seal System
Roller sealing design
for demanding conditions
Stock Support
Roller availability for
maintenance and breakdowns
Versatile conveyor roller systems engineered for multiple terminal-end configurations and demanding industrial conveyor environments.
Uni Rollers
UK-engineered roller systems designed to reduce stockholding complexity whilst supporting reliable conveyor performance and fast replacement availability.
Safer conveyor maintenance systems designed to improve return roller access and simplify replacement procedures.
Return Roller Lifting Cradles
Galvanised lifting cradle systems engineered to support safer, more controlled and efficient return roller replacement operations.
Conveyor frame systems manufactured to support structural alignment, belt tracking and heavy-duty operational performance.
Transoms & Frames
Laser-aligned and robotically welded conveyor frame assemblies designed for quarrying, aggregates and demanding bulk handling applications.
Conveyor loading-zone support systems engineered to protect belting and improve material transfer stability.
Impact Beds
Heavy-duty impact support systems designed to absorb loading forces, reduce belt damage and support cleaner transfer points.
Conveyor roller configurations and support systems tailored to different material handling duties and operational environments.
Types & Applications
Explore roller types, frame layouts, impact solutions and application guidance for quarrying, recycling, mining and industrial conveying.
Need support specifying conveyor rollers, frame assemblies or impact support systems for your operation?
Make An Enquiry Today!
Speak with QPI regarding roller specification, maintenance planning, frame compatibility and conveyor support system requirements.
Roller Types &
Applications
Conveyor roller and frame specification depends on belt duty, loading conditions, material characteristics, return-side requirements, impact zones, frame compatibility and long-term maintenance access.
Standard Idlers
Carrying & Support Rollers
Standard idlers support the carrying side of the conveyor belt and are specified around belt width, load, troughing angle, frame layout and site duty. Correct idler selection supports tracking, belt stability and consistent material flow.
Core Belt SupportSpiral Returns
Self-Cleaning Return Support
Spiral return rollers are commonly used where material carryback and build-up need to be reduced on the return side of the belt. Their spiral form helps shed material and support cleaner belt return operation.
Return-Side CleaningRubber Disc Returns
Build-Up Resistant Return Rollers
Rubber disc return rollers are suited to return belt positions where sticky, wet or difficult materials may create build-up. Disc spacing helps minimise material accumulation and supports improved belt tracking.
Carryback ControlImpact Rollers
Loading Zone Belt Protection
Rubber impact rollers are used around loading and transfer points to help absorb shock loads, protect the conveyor belt and reduce stress on the supporting conveyor structure.
Impact AbsorptionSuspended Sets
Field Conveyor Roller Sets
Suspended roller sets can be used on field conveyors and longer conveyor runs where flexible belt support, ease of replacement and heavy-duty material handling performance are required.
Field Conveyor SupportUni Rollers
One Base Roller, Multiple Ends
Uni Rollers are designed around a versatile base roller format that can accommodate multiple terminal-end arrangements, helping reduce stockholding complexity and improve response for maintenance or breakdown replacement.
Stockholding EfficiencyRoller Construction
Shell, Shaft & Seal Options
Roller specification can include shell thickness options from 3.6mm to 12mm, shaft and bearing diameters from 20mm to 50mm, a 5-seal system and roller ends manufactured to suit existing conveyor frames.
3.6–12mm / 20–50mmFrames & Transoms
Alignment, Tracking & Support
Conveyor frames and transoms support roller alignment, belt tracking and structural stability. Options can include in-line and staggered layouts, self-cleaning cross members and slotted tracking fixings for adjustment.
Frame CompatibilityImpact Beds
Transfer Point Belt Support
Impact beds support the belt through high-load transfer points, helping reduce belt damage, improve material containment and protect the conveyor structure around loading zones.
Loading Zone ProtectionHeavy-Duty Conveyor Rollers
Conveyor Frame Assemblies
Conveyor Roller Integration
Return Roller Systems
Rollers & Conveyor Components
Heavy Industrial Conveyor Support
